Long range portable walkie-talkie communicator. The RM-1560 is equipped for nationwide and global cellular connectivity with 4G LTE and has no range limit. The analog radio functionality connects with conventional walkie talkies as well as providing a back-up to the cellular connection.
IP66 certified this field device is waterproof, shock and dust proof.
A go-anywhere companion.
Have instant communication with all your field personnel and with no range limit.
With the REAL Mobile multi-carrier 4G LTE SIM this communicator goes Global!
Add the Administrative Dispatcher portal giving you access in REAL time with your field crew.
See where everyone is with your on-screen map, broadcast, single call and more ...
Long range portable wireless walkie-talkie
Monthly nationwide service for only $17.00
(Dispatcher console for only $10.00 monthly)
Specification | Parameter |
Model No | RM-1560 |
Dimension | 126mmx61mmx38mm |
Weight | 340g |
Working Temperature | -20℃~+60℃ |
Working Voltage | DC 7.5v |
Working Current | 250Ma @ UTMS 2100/900 |
Peak Current | 0.8A |
Working Range | UMTS/HSDPA 850/1900/2100 |
GSM/GPRS/EDGE B3, B8 LTE FDD:B2,B4,B5,B12,B17 |
Maximum Output Power | WCDMA 900/2100MHz:Power Class 3(+24dBm +2.5Bm/-1.5dBm) |
GSM/GPRS850/900MHz:Power Class(+33dBm +2.5Bm/-0.5dBm) |
GSM/GPRS1800/1900MHz:Power Class(+30dBm +2.5Bm/-0.5dBm) |
Receiving Sensitivity | WCDMA 900: ≤-108dBm |
WCDMA 2100: ≤-109dBm |
GSM 850/900/1800/1900: ≤-106dBm |
GPS | GPS Posotioning,1.57542GHz |
Batteru | 3000 mAh |
Sensitivity | Catch -144dBm,Track-159dBm |
Data Speed Rate | GSM CS:UL 9.6kpbs/DL9.6kpbs |
GPRS: Muiti-solt Class 10 |
EDGE: Muiti-solt Class 10 |
WCDMA CS:UL 64kpbs/DL 64kpbs |
WCDMA CS:UL 64kpbs/DL 64kpbs |
WCDMA PS:UL 384kpbs/DL 384kpbs |
Protocol | HSDPA/WCDMA/EDGE/GPRS/GSM |
Battery*1 , Antenna*1, Changer*1 , Belt clip*1 ,Hand strap*1 |
| Channel Capacity | 128 (400-520MHZ) |
| Channel spacing | 25kHz/12.5kHz |
| Operating voltage | DC 7.5v |
| frequency range | UHF |
| working mode | channel/frequency/channel + frequency |
| antenna impedance | 50 ohms |
| operating temperature | -20c - +60c |
| fm mode | FM |
| frequency stability | +- /-2.5ppm |
| reference sensitivity | > -121dBm |
| adjacent path sensitivity | >65dB |
| audio response | <=2dB & >= -10dB |
| rated audio power | 1000mW |
| receive signal-to-noise ratio | >=45dB |
| audio distortion | <=5% |
| co-channel suppression | >= 8dB |
| Attribute name | Attribute value |
|---|
| Modes | GSM 850/1900 |
| 4G | LTE FDD:B2,B4,B5,B12,B17 |
| 3G Data | 850/1900 |
| Functions | Group/Private/All Call Function |
| Battery Life | 3000 mAh Lithium Battery - 15 - 22 hours standby |
| Dimension | 126mmx61mmx38mm |
| Weight | 340g |
| Water Resistant | IP66 |
| GPS | GPS Posotioning,1.57542GHz ; |
